Agilent / Verigy / Keysight 41501B SMU and Pulse Generator Expander 2 units for Sale

De-installed from working condition in the fab.

The Keysight 41501B SMU and Pulse Generator Expander unit is available to augment the measurement capabilities of the 4155C and 4156C. The 41501B plugs into the rear of the 4155C/4156C, and its additional measurement resources are automatically recognized by the 4155C/4156C during boot-up. These additional resources appear in the 4155C/4156C “Channels: Channel Definition” page and they are treated exactly the same as the measurement resources of the 4155C/4156C

Config: HPSMU: 1Unit
PGU: 2Unit
 Parameter analyzer
Comments: Serial Number JP10E00262
Vintage 2001
OEM Agilent Technologies
Model 41501B
Measuring and analyzing the characteristics of Process semiconductor devices. SYSTEM CONFIGURATION
HPSMU: 1Unit
PGU: 2Unit
Spec. Options
HPSMU (High Power SMU) two pulse generator units (PGUs) (Option)
one high power source monitor unit (HPSMU: 10 fA/ V to 1 A/200 V)
or two MPSMUs (Option).
one ground unit (GNDU)
Voltage 0 V to 200 V
Current  1 pA to 1 A
Compliance accuracy Same as current (voltage) set accuracy.
GNDU (Ground Unit)
PGU (Pulse Generator Unit)
Output voltage 0 V  100 V
Sink current maximum 1.6 A
Output terminal/connection
Single triaxial connector,
Kelvin (remote sensing)
Modes pulse or constant
Amplitude 0 Vpp to 40 Vpp
Window -40.0 V to +40.0 V
Maximum current  200 mA (width: d 1 ms, average current d 100 mA)
100 mA
Output impedance 50  and low impedance (d 1  )
Burst count range 1 to 65535
Trigger output Level: TTL
Timing: same timing and width as PGU1 pulse output.
